MAGNDATA - Collection of Magnetic Structures

Symmetry operations of the magnetic space group in the setting used:

[Hide]

Symmetry operations of the magnetic point group in the setting used:

[Hide]

Magnetic atoms:

Label	Atom type	x	y	z	Occupancy	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Co1	Co	0.56925	0.64487	0.05364	1.	12	m_x,m_y,m_z	0.5(1)	0.78(7)	2.90(2)	2.98

Non-magnetic atoms:

Label	Atom type	x	y	z	Occupancy	Multiplicity
Te1	Te	0.85518	0.14482	0.00000	1.	6
Te2	Te	0.33333	0.66667	0.09040	1.	2
O1	O	0.79163	0.20837	0.76080	1.	6
O2	O	0.66570	0.94120	0.71930	1.	12
O3	O	0.59584	0.40416	0.40500	1.	6
O4	O	0.52617	0.47383	0.87520	1.	6
H1	H	0.88590	0.11410	0.00040	1.	6
O5	O	0.00000	0.00000	0.71700	1.	2
O6	O	0.88050	0.94020	0.00300	0.29	6

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:

Magnetic atoms:

Set of atoms in the unit cell related by symmetry with the magnetic atom Co1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.56925	0.64487	0.05364	m_x,m_y,m_z	0.50000	0.78000	2.90000
2	0.35513	0.92438	0.05364	-m_y,m_x-m_y,m_z	-0.78000	-0.28000	2.90000
3	0.07562	0.43075	0.05364	-m_x+m_y,-m_x,m_z	0.28000	-0.50000	2.90000
4	0.07562	0.64487	0.05364	m_x-m_y,-m_y,-m_z	-0.28000	-0.78000	-2.90000
5	0.35513	0.43075	0.05364	m_y,m_x,-m_z	0.78000	0.50000	-2.90000
6	0.56925	0.92438	0.05364	-m_x,-m_x+m_y,-m_z	-0.50000	0.28000	-2.90000
7	0.92438	0.56925	0.55364	-m_x+m_y,-m_x,-m_z	0.28000	-0.50000	-2.90000
8	0.43075	0.35513	0.55364	m_x,m_y,-m_z	0.50000	0.78000	-2.90000
9	0.64487	0.07562	0.55364	-m_y,m_x-m_y,-m_z	-0.78000	-0.28000	-2.90000
10	0.43075	0.07562	0.55364	-m_x,-m_x+m_y,m_z	-0.50000	0.28000	2.90000
11	0.92438	0.35513	0.55364	m_x-m_y,-m_y,m_z	-0.28000	-0.78000	2.90000
12	0.64487	0.56925	0.55364	m_y,m_x,m_z	0.78000	0.50000	2.90000

Non-magnetic atoms:

Set of atoms in the unit cell related by symmetry with the atom Te1:

Set of atoms in the unit cell related by symmetry with the atom Te2:

Atom	x	y	z
1	0.33333	0.66667	0.09040
2	0.66666	0.33333	0.59040

Set of atoms in the unit cell related by symmetry with the atom O1:

Set of atoms in the unit cell related by symmetry with the atom O2:

Set of atoms in the unit cell related by symmetry with the atom O3:

Set of atoms in the unit cell related by symmetry with the atom O4:

Set of atoms in the unit cell related by symmetry with the atom H1:

Set of atoms in the unit cell related by symmetry with the atom O5:

Atom	x	y	z
1	0.00000	0.00000	0.71700
2	0.00000	0.00000	0.21700

Set of atoms in the unit cell related by symmetry with the atom O6:

[Hide]

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Co1	Co	0.56925	0.64487	0.05364	12	m_x,m_y,m_z	0.5(1)	0.78(7)	2.90(2)	2.98

label	dim. small irrep	dim. full irrep	action	number of modes
mGM4	1	1	primary	3
